BST-FGS-SR Silicone Resin Fiberglass Sleeve is non-alkali fiberglass braided sleeve coated with silicone resin. Silicone
Description
Basic Info.
Model NO. | BST-FGS-SC |
Classification | Hybrid Insulation Materials |
Color | Upon Request |
Brand | Bstflex |
Near Port | Shanghai, Ningbo |
Transport Package | Carton Box |
Specification | Upon request |
Trademark | BSTFLEX |
Origin | China |
HS Code | 701959 |
Production Capacity | 1000000 |
Product Description
BST-FGS-SR Silicone Resin Fiberglass Sleeve is non-alkali fiberglass braided sleeve coated with silicone resin. Silicone Resin Fiberglass Sleeve is treated at a suitably high temperature to prossess excellent flexibility, toughness, self-extinguishment and dielectric strength, and to obtain a temperature classification of 200°C.It has especially good radiation resistance in addition to resistance to ozone, moisture, corona, weathering, fungus and chemical attack.
It is used in aerospace installations. It is used in the class H insulation system of electric motors,appliances,heating equipments,apparatus machinery,etc.
DATASHEET | |||||||||
Part Number | Bore Diameter (mm) | Wall Thickness (mm) | Meter for spool | ||||||
Normal | Tolerance | A | B, C, D | Meter | |||||
BST-FGS-SR-0.5 | 0.5 | 0.25 | 0.18 | 0.38 | 200 | ||||
BST-FGS-SR-0.8 | 0.8 | 0.25 | 0.18 | 0.38 | 200 | ||||
BST-FGS-SR-1 | 1 | 0.25 | 0.18 | 0.38 | 200 | ||||
BST-FGS-SR-1.5 | 1.5 | 0.25 | 0.18 | 0.38 | 200 | ||||
BST-FGS-SR-2 | 2 | 0.25 | 0.18 | 0.38 | 200 | ||||
BST-FGS-SR-2.5 | 2.5 | 0.25 | 0.18 | 0.38 | 200 | ||||
BST-FGS-SR-3 | 3 | 0.5 | 0.23 | 0.46 | 200 | ||||
BST-FGS-SR-3.5 | 3.5 | 0.5 | 0.23 | 0.46 | 200 | ||||
BST-FGS-SR-4 | 4 | 0.5 | 0.23 | 0.46 | 200 | ||||
BST-FGS-SR-4.5 | 4.5 | 0.5 | 0.28 | 0.5 | 100 | ||||
BST-FGS-SR-5 | 5 | 0.5 | 0.28 | 0.5 | 100 | ||||
BST-FGS-SR-6 | 6 | 0.5 | 0.28 | 0.5 | 100 | ||||
BST-FGS-SR-7 | 7 | 0.6 | 0.28 | 0.5 | 100 | ||||
BST-FGS-SR-8 | 8 | 0.6 | 0.28 | 0.5 | 100 | ||||
BST-FGS-SR-9 | 9 | 0.6 | 0.28 | 0.5 | 100 | ||||
BST-FGS-SR-10 | 10 | 0.8 | 0.4 | 0.6 | 100 | ||||
BST-FGS-SR-12 | 12 | 0.8 | 0.4 | 0.6 | 100 | ||||
BST-FGS-SR-14 | 14 | 0.8 | 0.48 | 0.68 | 50 | ||||
BST-FGS-SR-16 | 16 | 0.8 | 0.48 | 0.68 | 50 | ||||
BST-FGS-SR-18 | 18 | 0.8 | 0.48 | 0.68 | 50 | ||||
BST-FGS-SR-20 | 20 | 1 | 0.5 | 0.7 | 50 | ||||
BST-FGS-SR-22 | 22 | 1 | 0.5 | 0.7 | 25 | ||||
BST-FGS-SR-25 | 25 | 1 | 0.5 | 0.7 | 25 | ||||
BST-FGS-SR-30 | 30 | 1 | 0.5 | 0.7 | 25 |
